WF-8855E Deck Mount Converter

WF-8855E Deck Mount Converter

The WF-8855E Deck Mount Converter is a versatile, advanced power source solution for 220V AC-powered systems. The WF-8855E Deck Mount Converter provides 55 amps of clean, reliable DC power, which is ideal for powering electronics and appliances. It provides clean energy, even without filtering from a battery. Quiet operation is assured as the cooling fan runs only when needed.

Automatic three-stage battery charging maintains your battery’s life with three nominal voltage output modes: a 13.2V DC range “float” mode, a 13.6V DC range “absorption” mode, and a 14.4V DC range “bulk” charge mode. Electronic current limiting automatically shuts down the power during overload or short-circuit conditions.

To learn more about our products through video, click here. For any WFCO resources, tools, and information on our products, email support@wfcoelectronics.com with your request, or click here to download the WFCO Product Catalog.

Additional Information

Output Power

750 W

Input Voltage/Hz

190-240 VAC, 50 Hz

Output Current

55 A

Converter Type

Three-Stage Converter Charger

Voltage Output

13.2 – 14.4V DC Range

Absorption Mode (Nominal Voltage)

13.6V DC (nominal voltage)

Bulk Mode (Quick Charging Voltage)

14.4V DC (quick charging voltage)

Float Mode (Trickle Charge Voltage)

13.2V DC (trickle charge voltage)

Over Current

Yes

Over Temperature

Yes

Over Voltage

Yes

Reverse Polarity

Yes

Short Circuit

Yes

Cooling System

Yes

Dimensions

6.3˝ wide; 4.0˝ high; 10.2˝ deep

Weight

6.0 Lbs.
